ISO Tank
Cryogenic ISO Tank Container
The Cryogenic ISO Tank Container is a specialized transportation unit designed for the safe and efficient delivery of cryogenic fluids, such as liquefied natural gas (LNG), liquid oxygen, nitrogen, or argon. This container plays a crucial role in the logistics chain of cryogenics, enabling the reliable and secure transport of these ultra-cold fluids to their intended destinations.
Key Features
Cryogenic Storage Tanks: The Cryogenic ISO Tank Container incorporates robust cryogenic storage tanks that can withstand extremely low temperatures ranging from -260°F (-162°C) and below. These tanks are specifically designed to maintain the cryogenic state of the transported fluids, ensuring minimal temperature variations and reducing evaporative losses during transportation.
Product information
ISO tank containers are specially designed for the transportation of cryogenic liquids by road or sea, such as liquefied natural gas (LNG), liquid oxygen, liquid nitrogen, liquid argon, liquefied carbon dioxide, etc. The products can be designed according to ASME, EN, GB, DNV and Australian standards, and can also meet IMDG, ADR, CSC, RID, ISO1496/3, US.DOT, TSG, etc. They are suitable for road, water and rail transport containers worldwide.
Features
1. Light weight design to reduce transportation costs.
2. Standardized design to reduce maintenance costs.
3. Assembly line production to improve product consistency.
4. The full volume is maximized to improve the profit of customers. The vacuum performance of the product is stable, reliable, and longer product life.
|
Standard |
Type number |
Filling medium |
Working pressure |
Water capacity |
Material |
|
GB |
GXSCS-A22B(T75-20FT-22BAR) |
LCO2 |
2.2MPa |
21.6M3 |
WH590E/Q345R |
|
ASME |
TCSCS-D22C(T75-20FT-8BAR) |
LOX / LN2 / LAr |
0.8MPa |
21.7M3 |
SA240/Q345R |
|
EN13530 |
TCSCS-D22D(T75-20FT-18BAR) |
LOX / LN2 / LAr |
1.8MPa |
21.7M3 |
1.4315/Q345R |
|
ASME |
TCSCS-A20A(T75-20FT-22BAR) |
LOX / LN2 / LAr / LCO2 |
2.2MPa |
19.5M3 |
SA240M/Q345R |
|
EN13530 |
TSCSC-D22B-(T75-20FT-18BAR) |
LOX / LN2 / LAr / LNG |
1.8MPa |
21.7M3 |
1.4315/Q345R |
|
EN13530 |
TCSCS-D22E-(T75-20FT-18BAR) |
LOX / LN2 / LAr / LN2O |
1.8MPa |
21.7M3 |
1.4315/Q345R |
|
EN13530 |
TCSCS-A21A-(T75-20FT-22BAR) |
LOX / LN2 / LAr / LNG / LCO2 |
2.2MPa |
21.4M3 |
1.4315/Q345R |
|
ASME |
TCSCS-U46F-(T75-40FT-8BAR) |
LNG |
0.8MPa |
45.7M3 |
SA240M/Q345R |
