CLASSIFICATION
C2H6-Ethane (R170)
Keywords:
Category:
Hydrocarbon Gas
Hotline:
C2H6-Ethane (R170)
Ethane is an organic chemical compound with chemical formula C2H6. At standard temperature and pressure, ethane is a colorless, odorless gas. Like many hydrocarbons, ethane is isolated on an industrial scale from natural gas and as a petrochemical byproduct of petroleum refining. Its chief use is as feedstock for ethylene production. Ethane also can be used as a refrigerant in cryogenic refrigeration systems.
High purity ethane (N3.5 and above) is manufactured by direct hydrogenation of ethylene at high temperature in the presence of a catalyst. It is further purified using fractional distillation. Lower purity ethane is separated from a natural gas stream and further purified.
Standard Specifications
|
Purity / Assay |
2.5 |
3.5 |
4.5 |
5.0 |
|
Nitrogen |
< 100 |
< 50 |
< 5 |
< 3 |
|
Oxygen |
< 25 |
< 10 |
< 2 |
< 1 |
|
CO / CO2 |
< 30 |
< 10 |
< 4 |
< 2 |
|
Other hydrocarbons |
< 4000 |
< 400 |
< 40 |
< 6 |
|
Moisture ** |
< 10 |
< 5 |
< 5 |
< 3 |
|
Total Impurities |
< 5000 |
< 500 |
< 50 |
< 10 |
**Moisture Specification only guaranteed if cylinders prepared by Ludonggas.
Standard Cylinder Sizes and Fill Volumes
|
Cylinder Information |
|
|
Cylinder Size |
Fill Volume (kg) |
|
50L |
16.5 |
|
47L |
16 |
|
40L |
13 |
Technical Information
|
Technical Data |
|
Shipping Information |
|
|
Molecular Weight (g/mol) |
30.069 |
Shipping Name |
Ethane |
|
Liquid Density (kg/m³) |
546.5 |
Hazard Class |
2.1 |
|
Gas Density (kg/m³) |
1.282 |
UN No. |
UN 1035 |
|
Boiling point (°C) |
-88.7 |
Hazard Label |
Flammable gas |
|
Specific Volume (m³/kg) |
0.799 |
CAS No. |
74-84-0 |
|
Vapour Pressure (bar.a @ 20°C) |
38.3 |
|
|
|
Valve Outlet |
CGA 350/ BS-4 |
|
|
